KJP 0450-2B | Chain Pitch(P)=45mm
Mechanical Components » KJP Cable Chains
H value corresponding to the radius of curvature
| R | 50 | 75 | 95 | 125 | 150 | 200 |
|---|---|---|---|---|---|---|
| H | 140 | 190 | 230 | 290 | 340 | 440 |
A-A Cross Section / D.Max
End Bracket
